• Model No.: PFPFEVEX72917

• Frame / Type: Upright exercise bike — compact home cardio design

• Flywheel: 7 kg inertia-enhanced flywheel (smooth pedaling)

• Resistance: SMR™ silent magnetic resistance — 1–16 digital levels

• Display: 5" high-contrast multi-color display with workout feedback

• Workouts: 12 preset workout programs

• Heart Rate: Dual EKG pulse grips for quick heart-rate readouts

• Connectivity / Features: Adjustable tablet holder (iFit compatible), iPod-compatible sound system, water bottle holder, transportation wheels

• Max User Weight: 125 kg

• Item Weight: 39 kg

• Dimensions (L×W×H): 93 × 33 × 65 cm

• Warranty: 12 months

• Country of Origin: United States

How to assemble, set up and get the most from your ProForm 320 CSX+ Upright Bike

1. Unpack & Inspect (10–15 minutes)
   Open the boxed unit on a flat surface and lay out components: base stabilizers, main frame, seat post and saddle, handlebars, pedals, console, tablet shelf, hardware pack and tools. Check for shipping damage and confirm all parts against the included parts list. Keep the manual and small tools handy.

2. Assemble Base & Main Frame (10–20 minutes)
   Attach the front and rear stabilizers to the main frame using the supplied bolts and washers. Do not fully torque all bolts until the bike is standing square. Level the bike roughly on the floor and finger-tighten hardware to ensure parts align.

3. Install Seat, Handlebars & Pedals (10–15 minutes)
   Insert the seat post into the frame, set a comfortable starting height, then tighten the clamp. Attach the handlebars and route any console wires as instructed. Screw the right and left pedals into the crank arms (note: pedals are directional—tighten clockwise on the right, counterclockwise on the left). Once aligned, torque bolts to the manual’s recommended spec.

4. Mount Console & Tablet Holder (5–10 minutes)
   Connect the console cable to the console port and secure the display to the mast. Fit the tablet shelf and test power (if battery or adapter provided). Ensure the display mounts securely and shows initial power up metrics.

5. Adjust Ergonomics & Test Ride (10 minutes)
   Adjust saddle vertical and horizontal positions to match your leg extension—knee should have a slight bend at the bottom of the pedal stroke. Check handlebar reach for a comfortable posture. Perform a short test ride: cycle through several resistance levels and confirm the SMR response, console readings, and EKG pulse grip functionality.

6. Final Tightening, Safety Check & First Workout (5 minutes)
   Power off, re-check and fully tighten all bolts and pedal fittings, then re-power. Verify smooth operation across all 16 resistance levels and confirm the bike is stable (no wobble). Start with a 10–15 minute warm-up ride using one of the preset programs to validate settings and comfort.

Troubleshooting Tips

• Console won’t power: check battery/adapter and console cable seating.

• Resistance not changing: ensure console cable is connected and re-start the unit.

• Pedal creak or looseness: retorque pedals and crank bolts; inspect pedal straps.

• Uneven or noisy pedaling: verify flywheel assembly bolts and tighten frame fasteners.

Q1: What resistance system does the ProForm 320 CSX+ use and how quiet is it?
The ProForm 320 CSX+ uses SMR™ silent magnetic resistance across 16 digital levels. Magnetic resistance removes physical friction, producing a notably quieter ride than friction-based bikes. Because the resistance is digitally stepped, you’ll get consistent, repeatable intensity for interval sets and steady rides—useful in apartment or shared living environments in Dubai where low noise is important. The 7 kg inertia-enhanced flywheel further smooths pedal stroke for noise-reduced performance.

Q2: Which workout data and programs are available on the 5" display?
The 5-inch high-contrast display presents core workout metrics like time, speed, distance, RPM, and estimated calories. The bike is preloaded with 12 preset workout apps covering endurance, intervals, and recovery sessions. While not a full smart console, the display and tablet holder let you pair device-based apps (like iFit) via tablet to stream guided sessions and richer data. For everyday training the built-in programs plus the clear display provide structured, measurable rides.

Q3: Is the ProForm 320 CSX+ suitable for tall users and what is the maximum user weight?
Yes—the bike supports a maximum user weight of 125 kg, and the saddle offers vertical and limited horizontal adjustment to fit a variety of rider heights. While it’s compact (93 × 33 × 65 cm) and ideal for apartments or tight home gyms, very tall users should check saddle fore/aft range and handlebar comfort before purchase. The adjustable tablet holder and ergonomic pedal straps also help accommodate different shoe sizes and riding postures.

Q4: Does the bike offer heart-rate monitoring and connectivity options?
The 320 CSX+ features dual EKG pulse grips for quick heart-rate readings visible on the console. It also includes an adjustable tablet holder and iPod-compatible sound, allowing you to pair a tablet or device for guided workouts or audio. Note that it doesn’t include built-in Wi-Fi—connectivity for interactive training relies on your tablet/device and external apps for streaming guided classes.

Q5: What maintenance and setup should I expect for the ProForm 320 CSX+?
Setup typically involves attaching the stabilizer bars, seat, handlebars, pedals, and console—most users can assemble it in under an hour using the included hardware and basic tools. Routine maintenance is minimal: keep the frame clean, check pedal tightness and saddle bolts periodically, and ensure the console connections remain secure. Store indoors in a dry area to protect the electronics and magnetic resistance components from moisture.
