ENERGYCELL ER17330V 3.6V BATTERY with 2 pin connector battery

Voltage:           3.6V

Capacity:         1.2Ah (1200mAh) Nominal capacity is based on standard drain and cut-off voltage down to 2.0V at 20ºC (68ºF)

System :          Lithium thionyl chloride battery

Terminal :        with 2 pin connector

Cell type:         Toshiba Ultra Lithium ER17330/3.6V battery (2/3A size)

Battery Size:  Diameter ( dia. )17 mm x Height ( h )33 mm + 1

Weight :           18g

Continuous standard load:      2.5mA

Operating Temperature :         -40 °C to +85°C

For:                  Memory back-up Eternacell B9670E , Epson Equity IE , Bondwell B300 B310

Original Toshiba ER17330V Cylindrical Lithium Batteries are notable for their high voltage, energy density, durability, and stable operation. Many PLC/ Memory back-up machine have using the ER series lithium battery ,deal to Toshiba ER17330V lithium battery give a long shelf life and , This is good in for stand-by application

Fit or replace battery part no. (Cross refer or compatible)

Toshiba ER17330V/3.6V with 2 pin connector battery



Fit or replace product model: (Cross refer or compatible)

Eternacell B9670E battery

Epson Equity IE battery

Bondwell B300 battery

Bondwell B310 battery
